This Minecraft tutorial explains the NBT tags (formerly called data tags) that you can use for an armor stand in Minecraft Java Edition (PC/Mac) 1.16, 1.17, 1.18, 1.19 and 1.20.

TIP: If you are not running Minecraft Java Edition (PC/Mac) 1.16/1.17/1.18/1.19/1.20, find NBT tags for armor stand in another version of Minecraft:

  • Java Edition (PC/Mac) 1.14/1.15
  • Java Edition (PC/Mac) 1.11/1.12

Background

In Minecraft Java Edition 1.16, 1.17, 1.18, 1.19 and 1.20, the entity value for an armor stand is armor_stand. The armor_stand entity has a unique set of data tags that can be used in Minecraft commands such as: /summon and /data.

What are NBT tags (formerly called Data Tags)?

NBT tags allow you to set certain properties of an entity (such as armor_stand). The NBT tag is always surrounded in {} such as {ShowArms:1}. If there is more than one NBT tag used in a game command, the NBT tags are separated by a comma such as {ShowArms:1, NoGravity:1}.

List of NBT Tags

Here is a list of the NBT tags that you can use for armor_stand in Minecraft Java Edition (PC/Mac) 1.16, 1.17, 1.18, 1.19 and 1.20:

NBT Tag Value (Description)
Invulnerable 0 (The armor stand will take damage like normal)
1 (The armor stand will not take any damage from attacks or physical surroundings)

Example
{Invulnerable:1}

DisabledSlots

0 (All slots are enabled which means that items on the armor stand can be added, changed or removed)
1 (Adding or changing hand items is disabled)
2 (Adding or changing boot items is disabled)
4 (Adding or changing leggings items is disabled)
8 (Adding or changing chestplate item is disabled)
16 (Adding or changing helmet item is disabled)
256 (Removing or changing hand items is disabled)
512 (Removing or changing boots item is disabled)
1024 (Removing or changing leggings item is disabled)
2048 (Removing or changing chestplate item is disabled)
4096 (Removing or changing helmet item is disabled)
65536 (Adding hand items is disabled)
131072 (Adding boots item is disabled)
262144 (Adding leggings item is disabled)
524288 (Adding chestplate item is disabled)
1048576 (Adding helmet item is disabled)

Example
{DisabledSlots:0}

NoGravity

0 (The armor stand sits on the ground)
1 (The armor stand can float in the air)

Example
{NoGravity:1}

ShowArms

0 (The armor stand will not have arms)
1 (The armor stand will have arms)

Example
{ShowArms:1}

Invisible

0 (The armor stand is visible)
1 (The armor stand is invisible and only the items on the armor stand can be seen)

Example
{Invisible:1}

Small

0 (The armor stand is normal size)
1 (The armor stand is small)

Example
{Small:0}

OnGround

0 (The armor stand is not on the ground)
1 (The armor stand is on the ground)

Example
{OnGround:1}

NoBasePlate

0 (The armor stand has a base plate)
1 (The armor stand does not have a base plate)

Example
{NoBasePlate:1}

ArmorItems

Items of armor that are hanging on the armor stand, listed in this order: boots, leggings, chestplate, helmet

Syntax
ArmorItems:[{Count:1,id:item}, {Count:1,id:item}, {Count:1,id:item}, {Count:1,id:item}]

Example
{ArmorItems:[{Count:1,id:diamond_boots}, {Count:1,id:diamond_leggings}, {Count:1,id:diamond_chestplate}, {Count:1,id:diamond_helmet}]}

Pose

The pose for the armor stand which can be up to 6 data tags: Head, Body, LeftArm, RightArm, LeftLeg and RightLeg. (See below for explanation)

Syntax
Pose:{Head:[x,y,z], Body:[x,y,z], LeftArm:[x,y,z], RightArm:[x,y,z] ,LeftLeg:[x,y,z], RightLeg:[x,y,z]}

Example
{Pose:{Body:[0f,46f,0f], Head:[115f,0f,0f]}}

Head

It is used within the Pose data tag to specify the position of the head. It takes 3 values and each value can be between 0 and 360 (in degrees). The first value is the rotation around the x-axis, the second value is the rotation around the y-axis and the third value is the rotation around the z-axis.

Syntax
Pose:{Head:[x,y,z]}

Example
{Pose:{Head:[115f,0f,0f]}}

Body

It is used within the Pose data tag to specify the position of the body. It takes 3 values and each value can be between 0 and 360 (in degrees). The first value is the rotation around the x-axis, the second value is the rotation around the y-axis and the third value is the rotation around the z-axis.

Syntax
Pose:{Body:[x,y,z]}

Example
{Pose:{Body:[0f,46f,0f]}}

LeftArm

It is used within the Pose data tag to specify the position of the left arm. It takes 3 values and each value can be between 0 and 360 (in degrees). The first value is the rotation around the x-axis, the second value is the rotation around the y-axis and the third value is the rotation around the z-axis.

Syntax
Pose:{LeftArm:[x,y,z]}

Example
{Pose:{LeftArm:[19f,0f,0f]}}

RightArm

It is used within the Pose data tag to specify the position of the right arm. It takes 3 values and each value can be between 0 and 360 (in degrees). The first value is the rotation around the x-axis, the second value is the rotation around the y-axis and the third value is the rotation around the z-axis.

Syntax
Pose:{RightArm:[x,y,z]}

Example
{Pose:{RightArm:[19f,0f,0f]}}

LeftLeg

It is used within the Pose data tag to specify the position of the left leg. It takes 3 values and each value can be between 0 and 360 (in degrees). The first value is the rotation around the x-axis, the second value is the rotation around the y-axis and the third value is the rotation around the z-axis.

Syntax
Pose:{LeftLeg:[x,y,z]}

Example
{Pose:{LeftLeg:[50f,0f,0f]}}

RightLeg

It is used within the Pose data tag to specify the position of the right leg. It takes 3 values and each value can be between 0 and 360 (in degrees). The first value is the rotation around the x-axis, the second value is the rotation around the y-axis and the third value is the rotation around the z-axis.

Syntax
Pose:{RightLeg:[x,y,z]}

Example
{Pose:{RightLeg:[50f,0f,0f]}}

id

armor_stand (The entity value used to represent an armor stand in the EntityTag or Passengers tag)

Example
{id:armor_stand}

Target Selectors

Before we finish discussing data tags, let’s quickly explore how to use the @e target selector. The @e target selector allows you to target entities in your commands. If you use the type=armor_stand value, you can target armor stands:

@e[type=armor_stand]

Target Selector Examples

To change the nearest armor stand to be invisible:

/data merge entity @e[type=armor_stand,limit=1,sort=nearest] {Invisible:1}

To kill all armor stands:

/kill @e[type=armor_stand]

Next, learn how to use the game commands in Minecraft.

Command Examples

Here are some game command examples for an armor stand in Minecraft:

How to Show/Hide Arms on an Armor Stand
How to Summon an Armor Stand
How to Summon an Armor Stand with Chain Armor
How to Summon an Armor Stand with Diamond Armor
